kubectl annotate 命令详解

更新一个或多个资源的 Annotations 信息。

• Annotations 由 key/value 组成。
• Annotations 的目的是存储辅助数据，特别是通过工具和系统扩展操作的数据，更多介绍在这里。
• 如果--overwrite 为 true，现有的 annotations 可以被覆盖，否则试图覆盖 annotations 将会报错。
• 如果设置了--resource-version，则更新将使用此 resource version，否则将使用原有的 resource version。

有效资源类型包括：

• all
• certificatesigningrequests (aka 'csr')
• clusterrolebindings
• clusterroles
• clusters (valid only for federation apiservers)
• componentstatuses (aka 'cs')
• configmaps (aka 'cm')
• controllerrevisions
• cronjobs
• daemonsets (aka 'ds')
• deployments (aka 'deploy')
• endpoints (aka 'ep')
• events (aka 'ev')
• horizontalpodautoscalers (aka 'hpa')
• ingresses (aka 'ing')
• jobs
• limitranges (aka 'limits')
• namespaces (aka 'ns')
• networkpolicies (aka 'netpol')
• nodes (aka 'no')
• persistentvolumeclaims (aka 'pvc')
• persistentvolumes (aka 'pv')
• poddisruptionbudgets (aka 'pdb')
• podpreset
• pods (aka 'po')
• podsecuritypolicies (aka 'psp')
• podtemplates
• replicasets (aka 'rs')
• replicationcontrollers (aka 'rc')
• resourcequotas (aka 'quota')
• rolebindings
• roles
• secrets
• serviceaccounts (aka 'sa')
• services (aka 'svc')
• statefulsets
• storageclasses
• thirdpartyresources

语法

$ annotate [--overwrite] (-f FILENAME | TYPE NAME) KEY_1=VAL_1 ... KEY_N=VAL_N [--resource-version=version]

示例

更新 Pod“foo”，设置 annotation “description”的 value “my frontend”，如果同一个 annotation 多次设置，则只使用最后设置的 value 值。

kubectl annotate pods foo description='my frontend'

根据“pod.json”中的 type 和 name 更新 pod 的 annotation

kubectl annotate -f pod.json description='my frontend'

更新 Pod"foo"，设置 annotation“description”的 value“my frontend running nginx”，覆盖现有的值。

kubectl annotate --overwrite pods foo description='my frontend running nginx'

更新 namespace 中的所有 pod

kubectl annotate pods --all description='my frontend running nginx'

只有当 resource-version 为 1 时，才更新 pod ' foo '。

kubectl annotate pods foo description='my frontend running nginx' --resource-version=1

通过删除名为“description”的 annotations 来更新 pod ' foo '。#不需要- overwrite flag。

kubectl annotate pods foo description-

Flags

Name	Shorthand	Default	Usage
all		false	select all resources in the namespace of the specified resource types
allow-missing-template-keys		true	If true, ignore any errors in templates when a field or map key is missing in the template. Only applies to golang and jsonpath output formats.
dry-run		false	If true, only print the object that would be sent, without sending it.
filename	f	[]	Filename, directory, or URL to files identifying the resource to update the annotation
include-extended-apis		true	If true, include definitions of new APIs via calls to the API server. [default true]
local		false	If true, annotation will NOT contact api-server but run locally.
no-headers		false	When using the default or custom-column output format, don't print headers (default print headers).
output	o		Output format. One of: json|yaml|wide|name|custom-columns=...|custom-columns-file=...|go-template=...|go-template-file=...|jsonpath=...|jsonpath-file=... See custom columns [http://kubernetes.io/docs/user-guide/kubectl-overview/#custom-columns], golang template [http://golang.org/pkg/text/template/#pkg-overview] and jsonpath template [http://kubernetes.io/docs/user-guide/jsonpath].
output-version			DEPRECATED: To use a specific API version, fully-qualify the resource, version, and group (for example: 'jobs.v1.batch/myjob').
overwrite		false	If true, allow annotations to be overwritten, otherwise reject annotation updates that overwrite existing annotations.
record		false	Record current kubectl command in the resource annotation. If set to false, do not record the command. If set to true, record the command. If not set, default to updating the existing annotation value only if one already exists.
recursive	R	false	Process the directory used in -f, --filename recursively. Useful when you want to manage related manifests organized within the same directory.
resource-version			If non-empty, the annotation update will only succeed if this is the current resource-version for the object. Only valid when specifying a single resource.
selector	l		Selector (label query) to filter on, supports '=', '==', and '!='.
show-all	a	false	When printing, show all resources (default hide terminated pods.)
show-labels		false	When printing, show all labels as the last column (default hide labels column)
sort-by			If non-empty, sort list types using this field specification. The field specification is expressed as a JSONPath expression (e.g. '{.metadata.name}'). The field in the API resource specified by this JSONPath expression must be an integer or a string.
template			Template string or path to template file to use when -o=go-template, -o=go-template-file. The template format is golang templates [http://golang.org/pkg/text/template/#pkg-overview].
